DMS
Trained on massive real-world data, our core algorithm accurately detects driver fatigue and high-risk behaviors, such as smoking. Expertly optimized for low-light and obstructed views, it delivers reliable performance to prevent accidents.
1. High Accuracy: The mature algorithm ensures precise detection with minimal false alerts.
2. Multi-Scenario Awareness: Identifies phone use, gaze diversion, and head-turning.
3. Closed-Loop Alerts: Seamlessly activate ambient lighting and seat vibration for direct intervention.
Products
VDC-AVM100 Controller
SOC Chip ·············································································· RK3568
Computing Power······················································≥1Tops
Video Input ··········································································· 1× AHD/GMSL
Video Output ························································ ≤1×AHD
Memory Storage ························································ ≤8GB eMMC
CAN Interface ························································ ≤2
Protection Level ························································ ≤IP54
Operating Temperature ························································ ≤-40℃~85℃
Operating Voltage ························································ ≤9~36V
Major Functions ························································ ≤DMS
DMS Performance Parameters
Recognition Type ·············································································· Close Eye、 Yawn、 Look around、Telephone call、 Smoking
Detection Accuracy······················································≥95%
Operating Conditions ··········································································· >30km/h
Infrared Camera
Resolution ············································································· 1280×720
FOV angle ···················································HFOV：67.2º VFOV：37.8º
OAX4600
ARM A53 ·············································································· Tri-Core
DDR······················································≥inside DDR3L 2Gb
Computing power ··········································································· 2TOPS
Power consumption ························································ ≤560mW
UART························································ 4
MIPI CSI/DSI TX ························································ 1
MIPI CSI RX ························································ 2
Function safety ························································ ASIL B
Suitable Environments
Works normally in low-light environments
Can recognize faces even when obscured
Works normally in harsh light environments
